System Specifications

• CPU: Allwinner H618 | Quad-core | ARM Cortex™-A53
• GPU: Mali-G31
• RAM: 2GB
• STORAGE: 16GB
• OS: ATVSE Android 12
• Voltage: DC IN 5V/2A
• Power Consumption: 8W Max
• Operation Temperature: 0~40℃
• Humidity: <95%

I/O

• Video Output: HDMI2.0(4K60)
• Network: Buildin Wi-Fi antenna, Support USB RJ45 adaptive
• Peripheral Interface: USB2.0
• Power Interface: Type C USB (5V2A)
• Other Interface: IR receiver port

Features

• Network Streaming: HTML5, RTSP, HLS, Smooth streaming
• Multi-screen interactive: Miracast, DLNA and Airplay
• Local Media Playback: Video/Audio/Picture
• TV APP: Google Play(TV version), Google Voice Assistant, YouTube(4K), Netflix(TV Version), Disney+(TV Version), HBO, Max(TV Version), Other Android TV APP
• External Storage: USB storage max to 2TB (FAT32/NTFS)
• System Upgrading: Upgrading via USB disk or internet

Video

• Decoder:

• • H.265 Main10@L5.1 decoder up to 4K@60fps
  • VP9 Profile 2 decoder up to 4K@30fps
  • AVS2 JiZhun 10bit decoder up to 4K@30fps
  • H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps
  • Multi-format 1080p@60fps video playback formats, including H.264 BP/MP/HP, H.263 BP, VP8, MPEG-1 MP/HL, MPEG-2 MP/HL, MPEG-4 SP/ASP@L5, AVS+/AVS JiZhun, WMV9/VC1, etc

•  Format: MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc.

Audio

• Decoder: MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AACLC/HEAAC/HE-AAC v2, Real Audio, MPEG-H
•  Format: MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc.
• Subtitle Format: SMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation
• Photo Format: HD JPEG/BMP/GIF/PNG/TIFF
